不同的用途与简单/Brief Introduction：

全电脑电脑定时齿轮泵式膏体酱罐安装系统都是我新公司适应环境市場市场需求开发设计的新食材。该机型适用SUS304不锈钢材料齿轮泵式量值溯源泵执行命令罐装，且集电脑电脑定时上盖、电脑电脑定时旋盖、机械设备电气开关为集成，金钱好用，拆迁赔偿使用面积小，丰富应用于药厂、食材、除草剂、化工公司、定妆品等该行业的液态体产品包装，具备GMP规范性需求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优势特点/characteristic：

◆用齿轮泵式检定泵实行装罐，常用各项乳白色度夜体，误差高；泵的组成部分用快接式替换系统，用于洗、清洗。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆轴向柱塞泵式量值溯源泵汽缸环面料随着相关行业及固体成份的各个采取硅产品，四氟氯乙烯或各种面料，特出场景采取卫浴陶瓷面料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC掌握系統，变頻变速，自動化成度高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不装罐，主动运算工作。Lack of bottle filling, automatic counting function◆装量调准便于，可是一次调准整个收费泵的充填量，也可专门针对几大收费泵实现微幅调准；操作方法非常简单，调准很快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装罐设备针头要设防漏滴设备，充填时入侵瓶底装罐设备，过慢逐渐，以免泡沫。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整个机器可不适用各种不同产品规格的小瓶，变动便利，可在间歇间内达成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆机床按GMP需求设计制作。The machine designed according to the requirements of GMP

技术应用指标/technic parameter：

不适用水瓶座型号规格Size of bottles	20-1000ml（依据特殊要求订做）20-1000 - ml (according to your need）
应用塑料瓶子口径Apply the bottle diameter	¢20-¢150mm
可用盖子规格为Apply the lid specifications	¢20-¢70mm
产量技能 production capacity	四头灌装生产线：1000-2500瓶/小时左右 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/半小时 Eight head filling: 2500-4000 bottles per hour 12头罐装：4000-6000瓶/h 12 head filling: 4000-6000 bottles per hour
装量出现偏差的原因The load error	±1%
旋盖合理率Screw cover percent of pass	≥99%
电源模块power supply	380V，50HZ
公率power	3.0KW
供气gas sources	0.4-0.75MPA
进程把握speed control	变频式调压variable speed
