的主要用途与介绍/Brief Introduction：

该线由垂直式丝杆洗瓶烘干箱箱合二为一机、口服药液分装轧盖机二台单人包含，分成擦拭、非常干燥无菌和分装密封三种业务区，全面可联动机制产量，也可单人选用。可实现淋水、超声检查波擦拭、冲水、冲气、烘干箱箱无菌、放凉、分装、理盖、戴盖、轧盖等制作工艺。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

特别/Characteristic：

用于超声心动图波擦拭及雾水间歇性洗、远红外温度高无菌、空头灌装设备与封口处等技术性。整线三级联动自然控住。控制轻松便捷，控制了电气自动化成高一体化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

枝术参数表/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适用性外形尺寸 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(其中的顺利任务36Kw)(including normal working 36 kw)
工具净重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
